| 型号 | 重量 | 外形尺寸（mm） | 安装孔尺寸（mm） | 基本额定载荷（kN） | 极限转速（RPM） | | 径向 | 轴向 |
|
| | kg | Da | di | Ha | hi | Di | da | La | nB | dB | ds | ts | 动载荷 | 静载荷 | 动载荷 | 静载荷 | 带预压 | 有游隙 | | XV30 | 0.37 | 75 | 30 | 14 | 15 | 42.5 | 41.5 | 60 | 12 | 4.6 | 8 | 4.6 | 11.6 | 26 | 7.4 | 10.4 | 910 | 1819 | | XV40 | 0.44 | 85 | 40 | 14 | 15 | 52.5 | 51.5 | 70 | 12 | 4.6 | 8 | 4.6 | 13.6 | 34.5 | 8.7 | 13.8 | 735 | 1469 | | XV50 | 0.67 | 110 | 50 | 16 | 17 | 64.5 | 63.5 | 85 | 12 | 5.6 | 10 | 5.4 | 20.6 | 54 | 13.1 | 21.5 | 597 | 1194 | | XV60 | 0.75 | 110 | 60 | 16 | 17 | 74.5 | 73.5 | 95 | 16 | 5.6 | 10 | 5.4 | 22.6 | 64 | 14.4 | 25.5 | 516 | 1032 | | XV70 | 0.84 | 120 | 70 | 16 | 17 | 84.5 | 83.5 | 105 | 16 | 5.6 | 10 | 5.4 | 23.6 | 70 | 15.1 | 28 | 455 | 910 | | XV80 | 1.18 | 135 | 80 | 18 | 19 | 95.5 | 94.5 | 120 | 16 | 6.6 | 11 | 6.4 | 33.5 | 101 | 21.4 | 40.5 | 402 | 804 | | XV90 | 1.29 | 145 | 90 | 18 | 19 | 105.5 | 104.5 | 130 | 16 | 6.6 | 11 | 6.4 | 35 | 111 | 22.3 | 44.5 | 364 | 728 | | XV100 | 2.31 | 170 | 100 | 22 | 23 | 117.5 | 116.5 | 150 | 16 | 9 | 15 | 8.5 | 54 | 163 | 34.4 | 65 | 326 | 653 | | XV110 | 2.48 | 180 | 110 | 22 | 23 | 127.5 | 126.5 | 160 | 16 | 9 | 15 | 8.5 | 57 | 180 | 36.2 | 72 | 301 | 602 |
|
|
